BridgeWay for VME

Radio Interoperability Simplified!

BridgeWay™ provides switched radio, intercom, T1/E1/J1, VoIP and POTS interface controller board for Emergency Services, Homeland Security and Tactical Military Communications Systems.

The MediaPro BridgeWay audio controller board provides 4 or 12 channel multilevel audio interfacing, DSP audio processing, I/O channel switching, channel mixing, H.110 TDM interface and intercom/conferencing communications in a single 6U size VME board. Options include transformer isolation, a single FXS POTS interface, and a software-selectable T1/E1/J1 Network interface.

BridgeWay provides the following functions:

• Headset and Microphone interface with Push to Talk (PTT) control
• 4 Wire line inputs and outputs for interfacing to external audio equipment
• Audio file record and playback, with compression and time stamping options
• Voice controlled (VOX) record/transmit control modes
• Radio transmit control outputs for each channel
• Integrated I/O channel switching capability
• Optional DSP telecom signaling and audio processing software libraries
• Conferencing, mixing and “crash net” operation
• VME32, VME64 and VME64X compatible

Click here to download of Product Spec Sheet

Click here to download Voiceboard's Radio Interoperability White Paper
